RichAuto B55 Color Screen DSP Controller

B5X Series

RichAuto B55 Color Screen DSP Controller

Model B55

Three-axis color-screen controller with differential signal and analog spindle control.

#5-inch#Differential#Spindle
RFQWhatsApp

Known model facts

Brand
RichAuto
Series
B5X Series
Model
B55
Confirmed source dataB55 has no model-level source; all specs are from the B5X series specification sheet. 3-axis assignment is based on B5X series listing 3-4 output axes; confirm exact B55 axis count. Confirm exact B55 model differences from B51 and B57 before ordering.

Product overview

RichAuto B55 is the B5X series three-axis color screen controller positioned as a balanced option for production routers that need flexible I/O configuration without ATC or 4-axis complexity.

The B5X series source confirms DSP processor, 5-inch color screen, differential signal, USB/NETWORK communication, I16/O8 or I16/O16 wiring, 4M/s pulse frequency, analog spindle control, and handwheel support.

B55 offers flexible I/O with 16I/8O standard or 16I/16O extended options, making it suitable for multi-tool setups and production environments.

Source highlights

Display
5-Inch Color Screen
I/O
16I / 8O or 16I / 16O
Series
B5X Platform

Technical specifications

Processor
DSP
Display
5-inch color screen
Axes
3-axis
Control I/O
16 inputs / 8 outputs or 16 inputs / 16 outputs
Max. Pulse Frequency
4M/s
Control Signal
Differential signal
Communication
USB / Network
Spindle Control
Analog quantity
Analog Voltage
0-5V / 0-10V
Handwheel
Supported
Languages
Chinese / English
Standard Configuration
Handle with cable, wiring board, U disk, hook
RichAuto B55 Color Screen DSP Controller gallery reference
RichAuto B55 Color Screen DSP Controller gallery reference
RichAuto B55 Color Screen DSP Controller gallery reference
RichAuto B55 Color Screen DSP Controller gallery reference

Features

  • 5-inch color screen with USB/network communication.
  • Differential signal for stronger noise immunity.
  • 16I/8O or 16I/16O flexible I/O configuration for multi-tool setups.
  • Analog spindle control with 0-5V/0-10V voltage range.
  • Handwheel support for manual jogging and positioning.
  • 4M/s pulse frequency for higher-speed motion control.
  • Balanced B5X positioning for production environments.

Applications

  • Production routers
  • Woodworking machinery
  • Multi-tool setups
  • 3-axis production work

Selection notes

  • Confirm the machine needs a 5-inch color screen with 3-axis control.
  • Confirm whether 16I/8O or 16I/16O I/O configuration is needed.
  • Send photos of the current controller, wiring board, and driver type.
  • B55 data is based on B5X series specifications; confirm exact model before ordering.
